BUILD IT YOURSELF

Product Description:

Fully customizable with every option we recommend for watering individual pots. Use this page to create the exact kit you need, whether you're irrigating small 1-gallon containers or 200-gallon living soil pot.

1. Distribution Method Options:

Choose how you want water distributed around each pot.

• • None (1-5 gal) – No distribution; recommended only for small pots

  • 3-Dripper Setup (5-20 gal)– 3 drippers with stakes, connected by 3mm tubing

  • 5-Dripper Setup (10-30 gal) – 5 drippers with stakes, connected by 3mm tubing

  • 5" Drip Ring (2-7 gal) – 4 drip points; pre-assembled

  • 10" Drip Ring (10-20 gal) – 8 drip points; pre-assembled

  • BluSoak Plant Ring (30-90 gal) – Single loop for 30–90 gallon pots

  • BluSoak Spiral (30–90 gal) – Spiral layout from center outward

  • BluSoak Spiral (100–200 gal) – Larger spiral for big pots and beds

2. Sensor Type:

Choose between a 5-inch or 9-inch Blumat sensor depending on your desired sensing depth.

• 5-inch Sensor – Senses moisture at the soil surface. Perfect for small containers or crops with shallow root systems (<6").

• 9-inch Sensor – Adjustable to depths up to 9 inches. Senses moisture deeper into the container for more dynamic moisture control.

3. Calibration Type:

Decide between the Standard sensor or the upgraded Preset sensor.

Standard – Includes 6" of 3mm tubing (5" sensor) or 2 ft (9" sensor); ships as it comes from Blumat

Preset – Pre-calibrated and marked for gravity or pressure setups; includes locking adjustment cap, 3mm union, adjustment key, and extra 2 ft of 3mm tubing (for 5" sensor)

The Preset option offers more than just pre-calibration—it gives you added flexibility, control, and extra parts to customize your install.

Product Description:

Use this page to create the exact kit you need. Fully customizable with every option we recommend for irrigating raised beds. Choose a single kit for a small bed or multiple kits to cover any size area.

1. Distribution Method Options:

Choose a BluSoak layout that matches your bed dimensions.

• 2 Row (2×4 ft) – Two rows of BluSoak drip tape

• 3 Row (3×3 ft) – Three rows of BluSoak drip tape

• 3 Row (3×6 ft) – Three rows of BluSoak drip tape

• 4 Row (4×4 ft) – Four rows of BluSoak drip tape

• 4 Row (4×8 ft) – Four rows of BluSoak drip tape

BluSoak provides even, low-pressure watering and works great with both gravity-fed and pressurized systems.

2. Sensor Type:

Choose a single sensor or dual-sensor setup for your desired moisture control.

• 5-inch Sensor – Senses moisture at the soil surface. Perfect for beds with shallow-rooted crops (8" deep or less).

• 9-inch Sensor – Adjustable to depths up to 9 inches. Senses moisture deeper into the soil for more dynamic moisture control.

• 5-inch + 9-inch Sensors – Dual-depth control. Sensors work in tandem for the most precise and adjustable moisture response.

3. Calibration Type:

Decide between the Standard sensor or the upgraded Preset sensor.

• Standard – Includes 6" of 3mm tubing (5" sensor) or 2 ft (9" sensor); ships as it comes from Blumat

• Preset – Pre-calibrated and marked for gravity or pressure setups; includes locking adjustment cap, 3mm union, and adjustment key.

Product Description:

8mm Supply Line Kit, available in three lengths: 25 feet, 50 feet, or 100 feet. Each kit is made with our 8mm SuperFlex tubing that is almost kink-proof, lays down easily, and can snake around beds, pots, or corners with minimal resistance.

These kits make it easy to create a single irrigation zone from any water source—whether that’s a raised reservoir, pump, or hose bib. They can also be used with the Trunk Line Kit to complete multi-zone setups.

Each kit includes:

• 25 ft, 50 ft, or 100 ft of 8mm SuperFlex tubing

• 4 × 8mm Tees

• 3 × 8mm Blumat Shut-off Valves

Each length corresponds to the area it can typically irrigate:

• 25 ft kit = up to 25 square feet

• 50 ft kit = up to 50 square feet

• 100 ft kit = up to 100 square feet

Product Description:

This Trunk Line Kit is the foundation of a flexible, expandable irrigation system—perfect for larger gardens or complex layouts with multiple zones. Available in either 50 feet or 100 feet of durable ½-inch poly tubing, this kit allows you to deliver water from your source—whether it’s a raised reservoir or pressurized pump system—to several key locations throughout your garden.

Each kit includes up to six ½-inch to 8mm reducing tees with shutoff valves, so you can create distinct irrigation zones exactly where you need them. From there, you’ll connect 8mm Bluemat Superflex tubing to complete your system using one of our 8mm Supply Kits (sold separately), which include the tubing and shutoffs needed to feed your individual beds or rows.

This kit keeps things simple and scalable:

• Start with a central trunk line (main line)

• Branch off to each zone head using reducing tees with shutoffs

• Complete each zone using 8mm Superflex and Bluemat sensors

Whether you're irrigating beds, pots, or rows, this kit gives you a clean, organized way to manage multiple zones from a single water source.
