DescriptionThe Dosatron DifferenceDosatron units feature superior engineering to create the best solution injection product on the market. How does it work? The dosatron pulls up solution like a syringe drawing in the concentrate with the plunger. On the down stroke, the concentrate is displaced into the body of the Dosatron, where it mixes with incoming water. Then just the right amount of fertilizer is discharged into the water line. Dosatrons represent the highest quality, accuracy, reliable consistency, and long life - many times above copies like MixRite and other less expensive brands. Specs:
Connection Size:
3/4" NPT
Unit Weight:
6 lbs
Dimensions:
19 1/8" x 6 5/16"
Flow:
0.05 to 14 GPM (0.19 to 50 LPM)
Pressure:
4.3 to 85 PSI
Ratio Range:
1:500 to 1:50
Percentage Range:
0.2 to 2%
Ounces Per Gallon Range:
0.256 to 2.560
Included Accessories:
Mounting bracket, suction hose, weighted strainer, and quick start guide.
Description
This kit is ready for integration with dosatron systems or our high-flow pump kit. This features a BlueLab Guardian EC and pH monitor, so you know your fertilizer is being properly adminstered.
Description
The Dosatron DifferenceThis is the same as the D14MZ2 except it does a ratio of 1:3000 to 1:3333 or 0.03% to 0.3% of fertilizer to water ratio.Dosatron units feature superior engineering to create the best solution injection product on the market. How does it work? The dosatron pulls up solution like a syringe drawing in the concentrate with the plunger. On the down stroke, the concentrate is displaced into the body of the Dosatron, where it mixes with incoming water. Then just the right amount of fertilizer is discharged into the water line. Dosatrons represent the highest quality, accuracy, reliable consistency, and long life - many times above copies like MixRite and other less expensive brands.Specs: Connection Size: 3/4" NPT Unit Weight: 6 lbs Dimensions: 21" x 6 5/16" Flow: 0.05 to 14 GPM (0.19 to 50 LPM) Pressure: 4.3 to 85 PSI Ratio Range: 1:3000 to 1:333 Percentage Range: 0.03 to 0.3% Ounces Per Gallon Range: 0.0425 to 0.384 Included Accessories: Mounting bracket, suction hose, weighted strainer, and quick start guide.
DescriptionNew In-Line Fertilizer/Nutrient InjectorAdd nutrients to your reservoir as you fill it up, maintain the same mix ratio of 1:100 when you refill multiple times. Dosatrons represent the highest quality, accuracy, reliable consistency, and long life - many times above copies like MixRite and other less expensive brands. 1:100 fixed ratio (adjustable models also available for a higher price), 11 gpm max input flow.Specs:
Connection Size:
3/4" NPT
Unit Weight:
4 lbs
Dimensions:
14" x 6 1/4"
Flow:
0.05 to 11 GPM (0.19 to 42 LPM)
Pressure:
4.3 to 85 PSI
Ratio Range:
1:100 fixed
Percentage Range:
1%
Ounces Per Gallon Range:
1.280
Included Accessories:
Mounting bracket, suction hose, weighted strainer, and quick start guide.
Description
The Dosatron DifferenceThis is the same as the D14MZ2 except it does a ratio of 1:100 to 1:10 or 1% to 10% of fertilizer to water ratio.Dosatron units feature superior engineering to create the best solution injection product on the market. How does it work? The dosatron pulls up solution like a syringe drawing in the concentrate with the plunger. On the down stroke, the concentrate is displaced into the body of the Dosatron, where it mixes with incoming water. Then just the right amount of fertilizer is discharged into the water line. Dosatrons represent the highest quality, accuracy, reliable consistency, and long life - many times above copies like MixRite and other less expensive brands.
Specs: Connection Size: 3/4" NPT Unit Weight: 6 lbs Dimensions: 19 1/8" x 6 5/16" Flow: 0.05 to 14 GPM (0.19 to 50 LPM) Pressure: 7 to 85 PSI Ratio Range: 1:100 to 1:10 Percentage Range: 1 to 10% Ounces Per Gallon Range: 1.280 to 12.800 Included Accessories: Mounting bracket, suction hose, weighted strainer, and quick start guide.
Description
The Dosatron DifferenceDosatron units feature superior engineering to create the best solution injection product on the market. How does it work? The dosatron pulls up solution like a syringe drawing in the concentrate with the plunger. On the down stroke, the concentrate is displaced into the body of the Dosatron, where it mixes with incoming water. Then just the right amount of fertilizer is discharged into the water line. Dosatrons represent the highest quality, accuracy, reliable consistency, and long life - many times above copies like MixRite and other less expensive brands. Specs: Connection Size: 1 1/2" NPT Unit Weight: 12 lbs Dimensions: 25 1/4" x 8 1/2" Flow: 2.2 to 40 GPM (8.32 to 151 LPM) Pressure: 2.2 to 116 PSI Ratio Range: 1:500 to 1:50 Percentage Range: 0.2 to 2% Ounces Per Gallon Range: 0.256 to 2.560 Included Accessories: Mounting bracket, suction hose, weighted strainer, and quick start guide.
